PW-0860CLS2B
Aluminum Arch Low Profile Fully-Automatic Strapping Machine with Belts Tabletop
Description
CLS2B: Low Profile Aluminum Arch with Power Driven Belt Table and 2x Sensors.
- Low table bottom seal automatic strapping machine
- heavy and bulky packages
- low profile fully automatic strapping machine
- roll or belt driven - manufacturer from Taiwan
Specifications
| Power | 3 Ø, 220/380/415/440V, 50/60 Hz |
Standard Arch Size (WxH) | 850 x 600 (mm) 33.5 x 23.6 (in) |
PP Strap Width (mm) | 9,12 ,15,19 |
| Strapping Tension | 0~70 (kg) 0~154.3 (lb) |
| Strapping Speed | 2.4 sec / strap (25 Strap / min) |
| Max Load | 20 (kg) 44 (lb) |
Working Height | 450 (mm) 17.7 (in) |
Machine Size (LxWxH) | 2260 x 760 x 1774 (mm) 88.9 x 29.9 x 69.8 (in) |
Features
Mechatronic Aspect:
- Logic Relay Circuit
- Power Belt Conveyor Table
- Sensors for automatic strapping
- Belt type Strap Dispenser Brake
- Ready for in-line system control
Mechanical Aspect:
- Strap dispenser with belt brake
- Foldable tabletop
- Mechanical Tension adjustment
- Double cams for long lasting machine operation.
- New generation heating element suitable for PP and PET strap use, requires less initial heating time.
- Reinforced strap feed shooter structure gives much longer operation time before changing it.
Aluminum Arch:
- Increase strapping accuracy and reduce turn over strap, or tilted band position.
- 2 times lighter than the steel arch for handling.
- Modular extension, easier to add extra height or to replace a damaged section
- Easier to change wearable parts than the steel arch.
Application
Optional:
Mechantronic Aspect:
- PLC control integration
- Detection for strap feeding not to strap position
- Detection for no strap
- PET strap sealing
- Single Phase 1Ø , 110/220, 50/60Hz
- Enhanced PCB for faster cycle speed. (up to 36 straps per minute)
Mechanical Aspect:
- Pneumatic top press mechanism (Tighter strapping)
- Other arch size made on request
- PET strap
- Dispenser I.D. 9" (230mm)
- Extension conveyor
- Casters with brake
Special Needs:
- Stainless steel structure SUS #304
